进口机械隔膜计量泵（德国进口）品牌

机械隔膜计量泵（）品牌

German mechanical diaphragm metering pump

KAYSEN泵业中国总代理：营派阀门（上海）有限公司

Germany Kaysen Pumps China Distributor: Camper Valves (Shanghai) Co., Ltd.

KAYSEN凯森机械隔膜计量泵概述

German mechanical diaphragm metering pump

机械隔膜计量泵是电机通过直联传动带动蜗轮蜗杆副作变速运动，在曲柄连杆机构的作用下，将旋转运动转变为往复直线运动。

滑杆与膜片直接连接，工作时滑杆往复运动时直接推（拉）动膜片来回鼓动，通过泵头上的单向阀启闭作用完成吸排目的，达到输送液体的功能。2、是可以计量输送液体的机械，也叫定量泵、比例泵。通常描述为：机械隔膜计量泵是一种可以满足各种严格的工艺流程需要，流量可以在0-100%范围内无级调节，用来输送液体（特别是腐蚀性液体）一种特殊容积泵。分类一：根据过流部分：一、柱塞、活塞式；二、机械隔膜式；三、液压隔膜式。分类二：根据驱动方式：一、电机驱动；二、电磁驱动；三、气动分类三：根据工作方式一、往复式二、回转式；三、齿轮式其他的分类方式：电控型，气控型，保温型，加热型，高黏度型等。

The mechanical diaphragm metering pump is a motor that drives the worm gear and worm gear to perform a variable speed motion through a direct drive. Under the action of a crank and link mechanism, the rotary motion is converted into a reciprocating linear motion.

The slide bar is directly connected with the diaphragm. When the slide bar reciprocates, it directly pushes (pulls) the movable diaphragm to move back and forth. The purpose of the suction and discharge is achieved through a one-way valve on the pump head to achieve the function of conveying liquid. 2. It is a machine that can measure and transport liquids. It is also called quantitative pump and proportional pump. Usually described as: mechanical diaphragm metering pump is a kind of special volumetric pump that can meet various strict process flow requirements, flow can be adjusted steplessly in the range of 0-100%, used to transport liquids (especially corrosive liquids) . Category one: According to the flow part: one, plunger, piston type; two, mechanical diaphragm type; three, hydraulic diaphragm type. Category II: According to the drive mode: First, the motor drive; Second, the electromagnetic drive; Third, pneumatic classification three: According to the working mode one, reciprocating two, rotary; Three, gear other classification methods: electronic control, pneumatic control Type, insulation, heating, high viscosity and so on.

主要特点：

Features

冲程在静态及动态条件下均可调节

*额定流量Ф=500L/h

*排压：P2=1.2Mpa

*介质温度：-100C—1000C

泵调节范围10％-100％流量精<+1％

可安装隔膜破裂报警监测机构

多种材质泵头可选（PVC、PCDF、PTFE、304、316L）

机械驱动PTFE膜片

手动/自动冲程调节/数字变频控制均可选

Stroke can be adjusted under static and dynamic conditions

The maximum rated flow Ф = 500L/h

Maximum pressure release: P2=1.2Mpa

The maximum medium temperature: -100C-1000C

Pump adjustment range 10%-100% flow rate <+1%

Installable diaphragm rupture alarm monitoring mechanism

Multiple material pump head options (PVC, PCDF, PTFE, 304, 316L)

Mechanically driven PTFE diaphragm

Manual / automatic stroke adjustment / digital frequency control are optional

主要优点：

Advantage

机械驱动PTFE膜片（多种隔膜材质）

在泵运行或停止状态均可调节流量

安装空间小

多种材质及泵类结构可选

稳定精度±2%（调节比10%-100%）

坚固耐用，维护成本低

Mechanically-driven PTFE diaphragm (various diaphragm materials)

The flow can be adjusted when the pump is running or stopped

Small installation space

A variety of materials and pump structure optional

Stable accuracy ±2% (adjusting ratio 10%-100%)

Rugged, low maintenance costs

主要应用：

Application

石油化工

化工

电力

冶金

采矿

造船

轻工

农业

国防

Petrochemical

Chemical industry

electricity

metallurgy

mining

shipbuilding

Light industry

agriculture

national defense

KAYSEN的技术团队

Technical team

对几乎所有品牌和类型的泵进行快速有效的维护，修理和检修。

泵是您生产过程中不可缺少的元素。故障泵经常会导致生产能力下降甚至生产停机。凯森是几乎所有品牌和类型的泵快速和有效的维修，维修和大修的合作伙伴。多亏了凯森的机器诊断服务，您可以防止由于无法预料的机器停机而造成的生产中断。凯森还提供24小时的紧急泵问题的支持。我们提供量身定制的解决方案以满足您的所有需求。

有效和定期的维护对于泵的*运行至关重要。预防性维护有助于确保您不会面临突发的生产停机和相关费用。我们执行机器诊断服务来精确确定您的泵的状况。

Quick and efficient maintenance, repair and overhaul of almost all brands and types of pumps.

Pumps are an indispensable element of your production process. Faulty pumps often result in reduced production capacity or even production downtime. Kason is a fast and efficient maintenance, repair and overhaul partner for almost all brands and types of pumps. Thanks to Kayson's machine diagnostics service, you can prevent production interruptions due to unforeseen machine downtime. Kaysen also provides 24-hour emergency pump support. We provide tailor-made solutions to meet all your needs.

Effective and regular maintenance is critical to the optimal operation of the pump. Preventive maintenance helps to ensure that you do not face sudden production downtime and related expenses. We perform machine diagnostic services to accurately determine the condition of your pump.

   位于Schw?bischGmünd的凯森Kaysen泵业有限公司是*的各种流体水泵和隔膜泵制造商之一。60多年来，凯森以“制造”的可靠性和质量达到了*标准。凭借我们全面的产品组合，我们支持世界各地的客户成功掌握供水，采矿，工业，化工，造纸，电力，食品，制药，污水和海上行业的苛刻抽水任务。作为上述领域创新技术的*供应商，我们是液体需要安全，高效和经济运输的*合作伙伴。
       凯森始终坚持“重质量，讲信誉”为宗旨。产品现畅销全国各地，并已逐步开发海外市场。公司多次被评为“重合同讲信用”企业，深得用户的信赖和广泛的赞誉。

        The Kaysen Pumps GmbH in Schw?bischGmünd, Germany, is one of the world's leading manufacturers of fluid centrifugal pumps and diaphragm pumps. For more than 60 years, Kaisen has achieved the highest standards of reliability and quality of "Made in Germany". With our comprehensive product portfolio, we support customers around the world to successfully grasp the harsh pumping tasks of water supply, mining, industry, chemical, paper, electricity, food, pharmaceutical, sewage and marine industries. As a leading provider of innovative technology in these areas, we are the perfect partner for liquids to be safe, efficient and economical to transport. ,
         Germany Kaysen always adhere to the "quality, stresses credibility" for the purpose. Products are selling all over the country, and has gradually developed overseas markets. The company has repeatedly been rated as "the contract with the letter" business, won the trust of users and extensive praise.
